- Overview
- Related Products
2.2 W/FT(7.2W/M)
20 LEDs per pixel(36leds/ft
120 LEDs/m) 32.8ft(10m) max
run length ( standard model)
120 degree beam angle
Controlled with DMX512 IP20/65/ 67/68 rating
24V input
Ambient Temperature -25℃~+45℃
Storage Temperature -25℃~+60℃
Specifications:
| Product Model | LED Qty | IC Qty | IC Qty | IC Qty | PCB Width(mm) | Grey Levels | Pixels | Cut Length(mm) | CRI |
| WP-DMX512-2835White-70-IP20 | 70 | 10 | 24 | 14 | 12 | 256 | 10 | 100 | 80/90/95+ |
| WP-DMX512-2835White-96-IP20 | 96 | 8 | 24 | 12 | 10 | 256 | 8 | 125 | 80/90/95+ |
| WP-DMX512-2835White-112-IP20 | 112 | 4 | 24 | 9.6 | 10 | 256 | 4 | 250 | 80/90/95+ |
| WP-DMX512-2835White-120-IP20 | 120 | 6 | 24 | 7.2 | 10 | 256 | 6 | 166.66 | 80/90/95+ |
| WP-DMX512-2835CCT-144-IP20 | 144 | 6 | 24 | 8.64 | 10 | 256 | 6 | 166.66 | 80/90/95+ |
| WP-DMX512-2835White-240-IP20 | 240 | 10 | 24 | 14.4 | 30 | 256 | 10 | 100 | 80/90/95+ |
